LeGrand Adorne Touch Dimmer Graphite

RETAIL PRICE NEW $153.50

WALL PLATE SOLD SEPARATELY

FRAME SOLD SEPARATELY

Description

P&S ADTH4FBL3PM4 10V Dimmer

Technical Description: Wall Dimmer Switch Type; Magnesium Finish; 1-Pole, 3-Way Operation Type; UL (Canada and Us) Approval; 0 to 10 V Voltage Rating; Touch On/Off Switch Operator Type; Multi-Gang Wall Plate Type; Fluorescent, LED Load Type

UPC: 78500705595

Part Number: ADTH4FBL3PM4

Manufacturer: PASS & SEYMOUR

FEATURES

Helps fight the growth of stain and odor-causing bacteria through the invisible and continuous product protection of Microban® antimicrobial technology

For complete installation, device must be paired with an adorne® screwless Wall Plate (not included). Available in a range of contemporary colors and stunning finishes.

Installs in 15 minutes or less, fitting into an existing electrical box. No new wiring required for typical installation.

For use with dimmable 0-10V bulbs or fixtures. Features intuitive touch control for switching on/off and adjusting light levels.

Usable in both single-pole and 3-way applications.

SPECIFICATIONS

General Info

Color Graphite

Material Polycarbonate

Finish Metallic

Application Sector Commercial, Hospitality, Residential

Product Line Pass & Seymour

Country Of Origin China

Features Antimicrobial Protection, Locator Light, Low-End Trim (Dim Range)

Number of Switches 1

Switch Type Digital, Touch

Warranty Type Limited Lifetime Warranty

UPC Number 785007233889

Dimensions

Product Depth US 1.62 in

Product Height US 1.77 in

Product Width US 1.77 in

Technical Information

Requires Neutral Wire Yes

Wire Connection Type Flying Leads (0-10V), Screw Terminals

Dimming Compatibility 0-10 V

Frequency Rating 60 Hz

Indoor/Outdoor Indoor

Load Rating 120V 10A (Fluorescent), 120V 10A (LED), 277V 5A (Fluorescent), 277V 5A (LED)

Load Type Fluorescent, LED

Mounting Type Wall Box

Number of Poles Single Pole 3-Way

Voltage 120/277 VAC

Wire Size #14 - #10 AWG
